Miller Edge Transmitter RF in Nema 4 Enclosure *** To Extent of Inventory

Item #: MWT12
Manufacturer: Miller Edge

Product Discontinued

This product is no longer available for purchase

Replacement Information

MWT12 no longer available, replaced by the MWT12B.

Recommended Replacement

We suggest the following alternative for this product

Available Now

Miller Edge Transmitter Binary Nema 4 Enclosure

MWT12B Miller Edge Model: MWT12B
Product Specifications
  • The MWT12 safety edge transmitter is designed to provide wireless signal transmission form the safety edge to the motor controls.
  • It is easily mounted and wired to the gate or door edge sensor. When the sensing edge comes into contact with an obstruction a closed circuit signal is created and is sent to the transmitter.
  • The transmitter relays the information to the receiver and the receiver passes the signal along to the operator motor.
  • The gate or door stops movement and will then reverse the direction of travel.
  • Comes standard with a NEMA 4 weather-proof enclosure. The enclosure can be easily mounted with the four mounting holes and screws provided
  • Response time: 70 milliseconds
  • Opertating temperature: 0°F to 130°F (-18°C to 55°C)
  • Operating frequency: 318Mhz
  • Maximum operating distance: 100ft
  • Coding: Selectable 9 pole 2 position DIP switch
  • Power Source: (2) 1.5 volts AA alkaline batteries
  • Input/Output: Input: 2-wire N.O. sensing edge
  • Repl.: MWT12
