Manaras Monitored Entrapment Protection Option Upgrade Mont Thru-Beam + N1 Eyes

• Upgrades added when purchasing a commercial operator

Manaras Monitored Entrapment Protection Option Upgrade Mont + N4/12 Eyes

• Upgrades added when purchasing a commercial operator

Manaras Internet Control Device Modification (Op has to be compatible)

• The internet control device allows you to control and monitor your garage door from anywhere using the MIC app and your smart device
• Includes the MIC device and Wi-Fi compatible board & software
• Must be purchased and used with a Manaras monitored operator

Manaras Minimum Depth Mod. OTH OTBH

• Always use chain #41 with this mod.

Manaras Time Delay Mod. 1.5 Sec 24V for Contactor Models

• To be ordered in conjunction with a commercial operator
• Order MODKIT003 for field upgrades

Manaras Reverse Limits

• Necessary feature when the opening and closing of the door corresponds to a different rotational direction than the operator

Manaras Double Limit Switches Mod. (Per Side)

• An extra SPDT pole is available to control auxiliary features such as lights fans etc..
• The additional pole must be specified on either the normally open and/or normally close contact as well as on the opening and/or closing sides
• Modification upcharge is charged per side

Manaras Non-Resettable Counter Modification Inside Control Box

• An electromechanical counter is activated to count each complete door cycle.

Manaras Safepack 24V Control Circuit

• A safepack module is used as an "Intrinsically Safe Barrier Relay" and in hazardous locations with non-voltage producing sensors allowing the user to use a N.O. non-monitored sensing edge.

Manaras Auxiliary Output Module Modification

Manaras Universal Aux. Output Module B070 Red/Green 24V Modification

• MOD027B1 modification only when bought with operator
• Order MOD027B1 when ordered in conjunction with a commercial operator
• Works with BOARD070

Manaras Universal Aux. Output Module B070 Red/Green 24V w/Light Rapido Modification

• MOD027B1 modification only when bought with operator
• Order MOD027 when ordered in conjunction with a commercial operator
• Works with BOARD070

Manaras Monitored Photocell Upgrade N1 to N4

• Ideal for industrial environments submersible and impact resistant.
• Flexible design withstands and realigns after mechanical impact.
• Max. range 45ft.
• Incl. photoeyes 3ft of conductor wire and mounting hardware.
• Applies to all operator models with electronic control "M" types.

Manaras Monitored Photocell Upgrade N1 to N4X

• Ideal for industrial environments submersible and impact resistant.
• Flexible design withstands and realigns after mechanical impact.
• Max. range 45ft.
• Incl. photoeyes 3ft of conductor wire and mounting hardware.
• Applies to all operator models with electronic control "M" types.

Manaras Friction Clutch Mod. #50 Chain Gear Head Operators

• Installed directly on the output shaft of the operator.
• Provides added protection by causing the clutch to slip when the door systems requires adnormal torque to be operated.
• Includes sprocket for #50 chain
• Operator mounting side must be specified
• A spreader bar cannot be used in conjunction with this modification
• This modification applies to OGH and MGH operators

Manaras Friction Clutch Mod. #50 Chain 1-1/4 RGH

• Installed directly on the output shaft of the operator.
• Provides added protection by causing the clutch to slip when the door systems requires adnormal torque to be operated.
• Includes sprocket for #50 chain
• Operator mounting side must be specified
• A spreader bar cannot be used in conjunction with this modification
• This modification applies to RGH ops

Manaras Auxiliary Trolley #41 Chain Modification Only

• Provides drawbar operation of a standard lift door with the use of a jackshaft operator
• Includes tracks for doors up to 12' high. Additional fee for over 12'
• Maximum door width 22'

Manaras Auxiliary Trolley #41 Chain Modification Only

• Provides drawbar operation of a standard lift door with the use of a jackshaft operator
• Includes tracks for doors up to 12' high. Additional fee for over 12'
• Maximum door width 22'

Manaras Trolley Hoist Kit #410 Chain for OTH

• Modification when purchased with an operator
• #410 CHAIN WITH FRONTIDLER ASSY
• CHAIN HOIST ASSY
• HOIST KIT FOR TROLLEY HOIST CHAIN

Manaras Trolley Hoist #41 Brake Release Kit Includes 12' Shaft

• Chain hoist for manual hand operation of standard lift doors equipped with trolley operators.
• The 1" cross-header shaft (12' long) drives the front idler of the drawbar
• For use with operators with #41 chain
• When applicable it incorporates an electric cut-out and brake release cable
• Hand chain for 14' high door is standard
• Hoist assembly width is only 8.5"
