Linear 1-Channel MegaCode Gate Receiver 318 MHz *** Discontinued

• Activates one gate or device
• Supplied with F-connector and whip antenna
• Mounting bracket supplied
• Memory: storage for up to 40 MegaCode transmitters
• Power: 24 VAC/VDC
• Codes: 1000000+ (MegaCode format)
• RF frequency: 318 MHz
• Dimensions: 5.5" W x 4" H x 1.25" D
• Same as: DNR00073

Linear 1-Channel MegaCode Gate Receiver 318 MHz

• €¢Single Form ”A” (normally open) relay rated at 30 Volts AC/DC up to 5 Amps
• Supplied with whip antenna three feet of coaxial cable and bulkhead connector
• Memory: storage for up to 40 MegaCode transmitters
• Power: 12 - 30 VAC or 10.5 - 30 VDC
• Codes: 1000000+ (MegaCode format)
• RF frequency: 318 MHz
• Dimensions: 3.625" W x 5.25" H x 1.5" D
• Same as: DNR00104

Linear 2-Channel MegaCode Gate Receiver 318 MHz *** To Extent of Inventory

• Two Form ”A” (normally open) relays rated at 30 Volts AC/DC up to 5 Amps
• Supplied with whip antenna three feet of coaxial cable and bulkhead connector
• Memory: storage for up to 40 MegaCode transmitters
• Power: 12 - 30 VAC or 10.5 - 30 VDC
• Codes: 1000000+ (MegaCode format)
• RF frequency: 318 MHz
• Dimensions: 3.625" W x 5.25" H x 1.5" D
• Same as: DNR00105

Linear GTO Garage Door Receiver Adapter Mighty Mule

• The RB709 Garage Door Opener Adapter enables the Mighty Mule transmitters to open and close almost any garage door opener
• Made to be used with the FM134 (two button) and the RB743 (three button) remote control transmitters or F310 Keypad
• Easy to install with almost any garage door opener
• One RB709 is needed for each garage door opener that will be controlled by the Mighty Mule transmitters

Linear 1-Ch Gate Receiver MegaCode 318 MHz *** No Longer Available

• High gain superheterodyne receiver
• High RFI immunity
• Supplied with F-connector whip antenna and mounting bracket
• Memory: storage for up to 40 MegaCode transmitters
• Power: 24 VAC/VDC
• Codes: 1000000+ (MegaCode format)
• RF frequency: 318 MHz
• Dimensions: 5.5" W x 4" H x 1.25" D Order number: DNR00098

Linear Wiegand Output Receiver 318 MHz

• Designed for use as an access control interface for Linear’s block coded digital transmitters.
• The unit receives signals from transmitters adds a facility code to the data and sends the information to the Wiegand input of the access control panel via a 5-wire connection
• Ideal way to facilitate handicapped access
• Multi-button transmitters can double as personal emergency devices for triggering security alarms
• RF input/Wiegand output receiver supports 26 30 and 31-bit data formats
• Wide selection of MegaCode (over 1 million codes) format transmitters with available block coding
• Field adjustable read range - from 5 to 500 feet
• Connects as easily as a card reader; transmitters are added like cards with no software changes required
• Facility and ID codes tailored to system requirements
• Weather-resistant case for mounting outdoors
• RF frequency: 318 MHz
• Dimensions: 4.25" W x 6.25" H x 2.5" D
• Same as: ACP00727

Linear Single Channel Mid-Range Receiver ** Discontinued

• 1-channel mid-range receiver
• Up to 10 miles line-of-sight range (with XT-1 & XT-4)
• Up to 2 miles of line-of-sight with handheld devices
• Over 64 000 codes
• Weather-resistant case
• RF frequency; 27.255 MHz
• Dimensions: 4.25"W x 6.25"H x 2.5"D
• Power: 12 VDC
• Antenna (ANT-1A or ANT-2) not included
• Same as SSR00068

Linear 1-Channel Hand-Held Mid-Range Transmitter ** To extent of inventory

• Up to two miles of line-of-sight range
• RF transmit LED
• Push button activation
• Includes belt clip
• Antenna included
• Power: Two 9-volt batteries
• Codes: Over 64000
• RF frequency: 27.255 MHz
• Dimensions: 2.375" W x 12.25" H x 1.375" D
• Same as: SNT00395
