Miller Edge Field Configurable Sensing Edge Cut-to-Length

• For do-it-yourself edges on sectional or rolling doors.
• Black extrusion flexible PVC conductive polymer Ends: Molded polymer
• End plugs and mounting channel sold separately.
• Sensing edge size: 1-5/8"H (41mm) x 1-11/16"W (42mm)
• When combined with the ME123 mounting channel ideal for 2" thick surfaces
• Minimum Length: 3ft
• Billable Length: An edge that is 5'-2" is charged at 5' an edge 5'-2-1/2" is charged at 6'
• Lead Wire 12 in. 22 gauge SJTO
• Wire Outlet Location: Universal end plug
• Electrical Maximum 24 volts AC/DC 1/2 amp

Miller Edge Electronic Interface Module w/Junction Box (JB-02P-W)

• Designed for use with pre-UL325-2010 commercial door operators and Miller Edge CPT sensing edges.
• It's a durable weather-resistant solution housed in a NEMA 4-rated junction box.
• This module is particularly suited for overhead doors using retracting reels or coil cords

Miller Edge Protective Boot Covering for IG2 Eyes Sold as a Pair

Miller Edge Wall Mount Extension Bracket

• 1 ft L x 2" H x 3" W

Invisi-Guard-2 Photo Eye Kit 30ft Battery Powered *** Discontinued

• The Invisi-Guard-2 thru beam photo optic system sends an invisible beam of light from a transmitting unit to a receiving unit.
• The light beam is intended to function as a protective line guarding a potentially hazardous zone.
• When the light beam is interrupted by an obstruction a signal is sent to the motor controls to stop or reverse motion
• Universal Design Works with Pre and Post 2010 Operators
• Spans Distances up to 30 feet (model dependent)
• Time Saving Installation
• Vertical or Horizontal Mounting
• Easy Alignment with Positioning Indicators
• UL325 Compliant for Doors and Gates
• NEMA 4 enclosure
• Impact Resistant for rugged environments
• Easily Replaceable Batteries (no special order)
• Enhanced Sun Guard Protection
• Built in Strain Relie

Invisi-Guard-2 Photo Eye Kit 50ft Battery Powered *** Discontinued

• The Invisi-Guard-2 thru beam photo optic system sends an invisible beam of light from a transmitting unit to a receiving unit.
• The light beam is intended to function as a protective line guarding a potentially hazardous zone.
• When the light beam is interrupted by an obstruction a signal is sent to the motor controls to stop or reverse motion
• Universal Design Works with Pre and Post 2010 Operators
• Spans Distances up to 50 feet (model dependent)
• Time Saving Installation
• Vertical or Horizontal Mounting
• Easy Alignment with Positioning Indicators
• UL325 Compliant for Doors and Gates
• NEMA 4 enclosure
• Impact Resistant for rugged environments
• Easily Replaceable Batteries (no special order)
• Enhanced Sun Guard Protection
• Built in Strain Relief

Miller Edge Pair of Pedestal Mounts for IG2 Eyes

• Flexible spring loaded pedestal stand
• 30 degree of flex
• 27" high from bottom base to photoeye

Miller Edge Junction Box Metal

• For commercial overhead doors that use coil cords or retracting reels
• Standard metal junction box with cover
• Includes 1 x 90-degree connector 1 straight connector
• Includes strain relief + 2 wire nuts + pop-out holes
• For single-angle bottom bar of rolling steel door
• Also compatible with sectional door

Miller Edge Junction Box Nema 4

• For use with commercial door operators and CPT sensing edges from Miller Edge
• Waterproof
• Accommodates wire .181 to .312

Miller Edge Air-Wave Edge Black Sold per Foot

• This pressure sensitive air-wave edge can be adapted to suit a wide variety of applications.
• When touch activated the MAW123 sends an immediate pulse of air through the extrusion to an air-wave switch which sends a signal to controls to stop and/or reverse operations.
• It has been designed to fit most doors with double track bottom retainers.
• With appropriate mounting channel this edge will fit nearly all doors from 11/2" to 2" thick.
• The MAW123 is resistant to flame water and most common greases and oils.

Miller Edge Air-Wave Edge Black Sold per Foot

• This pressure sensitive air-wave edge can be adapted to suit a wide variety of applications.
• When touch activated the MAW123 sends an immediate pulse of air through the extrusion to an air-wave switch which sends a signal to controls to stop and/or reverse operations.
• It has been designed to fit most doors with double track bottom retainers.
• With appropriate mounting channel this edge will fit nearly all doors from 11/2" to 2" thick.
• The MAW123 is resistant to flame water and most common greases and oils.

Miller Edge Air-Wave Edge Black Sold per Foot

• This pressure sensitive air-wave edge can be adapted to suit a wide variety of applications.
• When touch activated the MAW123 sends an immediate pulse of air through the extrusion to an air-wave switch which sends a signal to controls to stop and/or reverse operations.
• It has been designed to fit most doors with double track bottom retainers.
• With appropriate mounting channel this edge will fit nearly all doors from 11/2" to 2" thick.
• The MAW123 is resistant to flame water and most common greases and oils.

Miller Edge Air-Wave Edge Yellow Sold per Foot

• This pressure sensitive air-wave edge can be adapted to suit a wide variety of applications.
• When touch activated the MAW123 sends an immediate pulse of air through the extrusion to an air-wave switch which sends a signal to controls to stop and/or reverse operations.
• It has been designed to fit most doors with double track bottom retainers.
• With appropriate mounting channel this edge will fit nearly all doors from 11/2" to 2" thick.
• The MAW123 is resistant to flame water and most common greases and oils.

Miller Edge MC22 2-Wire Non-Monitored Left Hand Gray Includes Funny Flaps - Sold per Foot

• €¢Electromechanical sensing edge for use on Cornell doors. •The MC22 is manufactured to exact specifications. •The MC22 is completely flexible and will contour to curved surfaces. •Touch sensitive signaling allows immediate reversing or stopping of motion. •Temperature range: -30F to 155F •Lead wire: 22 gauge universal •Sensitivity: nominal 6-8 PSI •2 wire NO configuration •Vertical or horizontal mount •One year warranty

Miller Edge MC22 2-Wire Non-Monitored Right Hand Black Includes Funny Flaps - Sold per Foot

• €¢Electromechanical sensing edge for use on Cornell doors. •The MC22 is manufactured to exact specifications. •The MC22 is completely flexible and will contour to curved surfaces. •Touch sensitive signaling allows immediate reversing or stopping of motion. •Temperature range: -30F to 155F •Lead wire: 22 gauge universal •Sensitivity: nominal 6-8 PSI •2 wire NO configuration •Vertical or horizontal mount •One year warranty

Miller Edge MC271 2-Wire Monitored Right Hand Gray Includes End Flaps - Sold per Foot

• Ideal for Cornell double angle bottom bar
• Flexible and will conform to floor irregularities
• Optimum size for 2+ inch thick surfaces
• Custom manufactured to user specifications for color length and outlet location
• 5-inch end flaps create a complete seal and can be trimmed for custom fit
• Sealed assembly impervious to dust and debris
• UL 325 Recognized Component
• Made in USA

Miller Edge MC271 2-Wire Non-Monitored Right Hand Black Includes End Flaps - Sold per Foot

• Ideal for Cornell double angle bottom bar
• Flexible and will conform to floor irregularities
• Optimum size for 2+ inch thick surfaces
• Custom manufactured to user specifications for color length and outlet location
• 5-inch end flaps create a complete seal and can be trimmed for custom fit
• Sealed assembly impervious to dust and debris
• UL 325 Recognized Component
• Made in USA

Miller Edge MC271 2-Wire Non-Monitored Right Hand Gray Includes End Flaps - Sold per Foot

• Ideal for Cornell double angle bottom bar
• Flexible and will conform to floor irregularities
• Optimum size for 2+ inch thick surfaces
• Custom manufactured to user specifications for color length and outlet location
• 5-inch end flaps create a complete seal and can be trimmed for custom fit
• Sealed assembly impervious to dust and debris
• UL 325 Recognized Component
• Made in USA

Miller Edge 2-Wire Black End Outlet 7/8" wide x 3/4" high Sold by the Foot

• Electromechanical slide in edge for counter shutters rolling doors and barrier arm applications.
• Touch sensitive signaling allows for immediate stopping and reversing of motion.
• Temperature range -30F to 155F
• Lead wire: 22 gauge universal
• Sensitivity: nominal 6-8 PSI
• 2 wire NO configuration
• Vertical or horizontal mount
• ANSI/UL325 recognized component
• Mounting channel sold seperately
• One year warranty

Miller Edge 2-Wire Black Left Hand Outlet 7/8" wide x 3/4" high Sold by the Foot

• Electromechanical pressure sensitive edge for counter shutters rolling doors and barrier arm applications.
• Touch sensitive signaling that allows for immediate stopping and reversing of motion.
• Temperature range -30F to 155F
• Lead wire: 22 gauge universal
• Sensitivity: nominal 6-8 PSI
• 2 wire NO configuration.
• Vertical or horizontal mount
• ANSI/UL325 recognized component
• Mounting channel sold seperately
• One year warranty
