FAAC Hydraulic Swing-Leaf Gate Operator S450H 24VDC

• Hydraulic operator for residential and condominium swing gates with single-leaf max width of 3 m (SB) and 2 m (CBAC).

FAAC 400 Hydraulic Swing Gate Operator 115V Reburbished

• Refurbished unit.
• Tank body

FAAC 400-220V Operator Only ** Price by Quote Only

FAAC 422-115V Operator Only ** Price by Quote Only

NICE Big-Metro Single Arm Kit

• For swing gates with leaves up to 5 m
• Underground installation.
• BM5024 Motor: Irreversible 24 Vdc with magnetic encoder complete with connecting lever and mechanical stop for the closing manoeuvre.
• Compatible with 2 foundation metro boxes externally chamfered with mechanical stop on opening: in stainless steel (BMBOXI) ideal for use in extreme conditions and with the new cataphoresis paint finish (BMBOX) highly resistant to corrosion.
• Maximum freedom of choice: release from inside or outside two key or lever operated models freely combinable and easy to operate with just one hand.
• Recommended control unit: Moonclever MC824H Features: Simple programming by means of a single key;
• self-learning of opening and closing limit positions;
• self-diagnostics of faults;
• programming of pause time;
• pedestrian pass door;
• deceleration on opening and closing;
• obstacle detection with dual technology;

LiftMaster Commercial High-Traffic Swing Gate Operator 1 HP 120VAC **Include part 75-50293

• First choice for heavy-traffic applications such as large gated communities residential developments commercial complexes and private estates.
• Unlike other systems the CSW gate operators are designed with a "non-scissor action" swing arm to greatly reduce the risk of injury
• Bi-Part Delay Monitors and adjusts speed and position of each wing to ensure primary gate closes last.
• Synchronized Close Simultaneously closes gates.
• Pre-Motion Warning Alarm Activates onboard alarm three seconds prior to gate motion.
• External Alarm Reset Button Instantly resets the built-in safety alarm siren.
• Monitored Safety Inputs 3 Main Board 3 Expansion Board.
• SECURITY+ 2.0® On-Board Radio Reciever Up to 50 remote controls (unlimited with 811LM/813LM).
• Gate Travel Speed 90-degree opening in 13-15 seconds.
• Height: 27.99” x Width: 15.20” x Depth: 24.75”
• Heater NOT included - sold separately # HTRNB

LiftMaster Commercial High-Traffic Swing Gate Operator 1/2 HP 120-240VAC

• First choice for heavy-traffic applications such as large gated communities residential developments commercial complexes and private estates.
• Unlike other systems the CSW gate operators are designed with a "non-scissor action" swing arm to greatly reduce the risk of injury
• Bi-Part Delay Monitors and adjusts speed and position of each wing to ensure primary gate closes last.
• Synchronized Close Simultaneously closes gates.
• Pre-Motion Warning Alarm Activates onboard alarm three seconds prior to gate motion.
• External Alarm Reset Button Instantly resets the built-in safety alarm siren.
• Monitored Safety Inputs 3 Main Board 3 Expansion Board.
• SECURITY+ 2.0® On-Board Radio Reciever Up to 50 remote controls (unlimited with 811LM/813LM).
• Gate Travel Speed 90-degree opening in 13-15 seconds.
• ½ HP – Rated for gates up to 18 ft. in length or weighing up to 1600 lbs.
• Heater NOT included - sold separately # HTRNB

LiftMaster 24VDC High Traffic Commercial Swing Operator

• 24VDC swing gate operator with battery backup
• Heater NOT included. Heater sold separately # HTR
• Continuous-duty motor with soft start/stop
• Receiver holds up to 50 remotes
• Power: 115V or 220V Single Phase
• Built-in surge protection
• Gate travel speed: 90 degrees in 13-16 seconds
• Equipped with MyQ and Security+ 2.0 technology
• Includes: LMRRUL Monitored Retro Reflective Photo Eye enhanced retro-reflective photo eye now with heater and wider polarized beam engineered to stay aligned; max. Range: 50 ft.

Liftmaster Heavy-Duty Variable Speed Swing Gate Op. 24VDC Heater Not Incl.

• Includes safety device LMRRUL Monitored Retroreflective Photo Eye enhanced retro-reflect
• Features battery backup that provides up to 45 cycles or 120 days of standby power
• Smooth Start/Stop Operation and mid-travel reversal extend operator and hardware life.
• Heavy-Duty Commercial Gear-Driven Transmission provides unsurpassed reliability.
• myQ® Technology enables you to securely control and monitor your gate operator from anywhere
• Security+ 2.0® safeguards access with an encrypted tri-band signal to virtually eliminate interference and offer extended range.
• Emergency Disconnect: simple-to-use release handle allows gate to be operated manually and maintain limit position once reengaged.
• Fire Department Compliance allows gate to auto-open upon loss of ac power or battery depletion.
• UL® Listed gate operators with monitored safety entrapment protection devices
• Operator Duty Rating: Continuous-duty

LiftMaster Residential 24VDC Linear Actuator Secondary Arm Only New Model

• Secondary Arm Only for LA400
• All new arms are backwards compatible with the previous model but the LiftMaster branding is different

LiftMaster Residential 24V DC Swing Gate Operator All-In-One UL325

• LED DIAGNOSTIC DISPLAY Simplifies installation and troubleshooting.
• WIRELESS DUAL-GATE COMMUNICATION Eliminates expensive conduit costs and unsightly driveway scars.
• BI-PART DELAY Monitors and adjusts speed and position of each wing to ensure primary gate closes last.
• SYNCHRONIZED CLOSE Simultaneously closes gates. WITH OPTIONAL EXPANSION BOARD
• PROGRAMMABLE AUXILIARY RELAYS Easily add additional features such as warning lights/alarms.
• ANTI-TAILGATE Prevents unauthorized access. Gate will pause when closing as vehicle pulls onto interrupt loop or breaks photo beam. Once vehicle backs up gate will continue to close.
• QUICK CLOSE Closes the gate immediately after a vehicle pulls off the interrupt loop.
• HOMELINK® COMPATIBLE Version 4 and higher.
• SECURITY+ 2.0® ON-BOARD RADIO RECEIVER Up to 50 remote controls (unlimited with 811LM/813LM).
• OPERATOR DUTY RATING 100 cycles per day.
• Meets new 2016 UL325 gate guidelines
• Comes with LMRRUL
• Includes (2) 7Ah

LiftMaster Residential / Light Comm. DC Swing Gate Op. Extra Large Control Box UL325 (Includes LA500CONTXLMUL (K74-39309-1) LA500DC (2x) 29-NP712 LMRRUL)

• LA5001PKGXLMU replaces model LA5001PKGXLMDC
• Updated unit complies with new UL325 code revised Jan 2016
• System now requires monitored secondary entrapment devices unit will include LMRRU safety photo eye
• Includes one LA500 arm XL control box receiver unit and photo eye and 2 -7amp batteries
• Residential arm style swing gate operator with Extra Large control box and battery backup system
• Battery Backup safeguards your property by providing up to 500 cycles* or up to 24 days* of standby power when the power is down.
• Solar Ready Ultra Reliable System delivers power when you need it most to operate the gate and is extremely power efficient at all other times to maximize solar performance.
• Gate Size rated for gates up to 18 ft. in length or weighing up to 1600 lbs.
• Commercial Duty Cast Aluminum Housing with Heavy-Duty DC Motor powerful enough to perform in the most demanding applications. Soft start/stop operation extends operator and hardware life for HD gate use

LiftMaster Residential / Light Commercial DC Swing Gate Operator All-In-One UL325

• UL 325 Rated Class I II II and IV
• Continuous-duty (300 cycles/day) P3 24 VDC motor
• Operates gates up to 18 ft. long or up to 1600 lbs.
• Includes battery backup (2 12 VDC 7Ah batteries) receiver photo eye
• Compatible with MyQ Security+ 2.0 accessories
• HomeLink-compatible
• Gate travel speed: 90-degree open in 15-17 sec.
• Maximum travel range: 115 degrees
• Security+ 2.0 receiver can handle up to 50 remotes
• Can be adapted for solar power wireless dual-gate communications
• Auxiliary relays for warning lights alarms other accessories
• Anti-tailgate safety protection
• Incl. installation brackets for post gate (9"x2-1/4" & 6"x2-1/4")
• Operating temperature range: minus 4º F to 140º F
• Heavy-duty aluminum die-cast chassis housing
• Precision-machined worm gear reduction
• Weight: actuator arm = 35 lbs. control box = 13 lbs.
• Control box size: 14-3/8"x 6-9/16"x 16-7/16"
• Actuator arm size: 40-3/8"L x 4-3/16"W x 5-13/16"

NICE Barrier Gate Op. w/Heater 5M (16') Arm Package 110VAC

• Electromechanical road barrier system for control of road access.
• 24 Vdc gearmotor
• Robust structure in steel new high strength balancing springs guaranteed up to 1000000 opening and closing operations and elliptical section bar with high wind-gust resistance.
• Work cycle (cycles/hour): 350
• Working temp. (°C Min/Max): -20 ÷ +50
• Packing includes: Heater Aluminum Arm Rubber impact protection strip and sticker kit
• Arm/Bar dimensions: 69 X 92 X 5150MM

NICE Barrier Gate Op. w/Heater Arm Package 110VAC

• 16 to 23 ft Arm Length
• 120VAC Power Source / 24VDC Operational Voltage
• Open/Closes in 6 - 10 seconds
• 200 Cycles/Hour
• Aluminum arm with red adhesive reflector and optional lights/bumper strips
• ETL Listed (UL325)
• Usage Class I II III IV

Lux 2B Hydraulic Swing Gate Operator 120V UL/CSA

• Leaf Weight: Up to 660 lbs (300 Kg)
• Leaf Length: Up to 10ft (3 m)
• Opening / Closing time: 17 seconds

LiftMaster Res. / Light Comm. DC Swing Gate Operator 12VDC Heater Not Incl.

• Includes safety device LMRRUL Monitored Retroreflective Photo Eye enhanced retro-reflect
• Features battery backup that provides up to 147 cycles or 63 days of standby power
• Smooth Start/Stop Operation and mid-travel reversal extend operator and hardware life.
• Heavy-Duty Commercial Gear-Driven Transmission provides unsurpassed reliability.
• myQ® Technology enables you to securely control and monitor your gate operator from anywhere
• Security+ 2.0® safeguards access with an encrypted tri-band signal to virtually eliminate interference and offer extended range.
• Emergency Disconnect: simple-to-use release handle allows gate to be operated manually and maintain limit position once reengaged.
• Fire Department Compliance allows gate to auto-open upon loss of ac power or battery depletion.
• UL® Listed gate operators with monitored safety entrapment protection devices
• Operator Duty Rating: 250 cycles per day
• Optional expansion board: K1D8387-1CC
