LiftMaster Non-Resettable Counter Field Kit

• A 6-digit non-resettable 24VAC electro-mechanical counter is mounted in the operator control enclosure.
• This devise counts the number of times the CLOSE coil is energized or whenever the operator reaches an auxiliary open limit switch.
• This corresponds to the number of complete door cycles of use.

LiftMaster Field Mod. Dual Aux. Limit Switch

LiftMaster Auxiliary Limit Switch Mod M62 Open Factory Installed

• Provides a limit switch for use by others to control auxiliary devices such as lights heaters dock levelers or other equipment.
• The switch can be used to turn on or off such equipment when the door is fully opened or fully closed.
• When ordering specify whether the auxiliary switch is required on the OPEN or CLOSE side of the control enclosure.
• A maximum of 2 switches per operator can be supplied.
• Each switch is SPDT (form C) and is rated 10 amps at 125/250 VAC
• Wire leads are provided on field install kits

Micanan Intrinsically Safe Modification (Safepack)

• Modification available for add-on to certain models only

Micanan Surface Mount Fused Disconnect Modification

• Mounted to control panel cover in lieu of primary fuse block inside panel

Manaras Reverse Limits

• Necessary feature when the opening and closing of the door corresponds to a different rotational direction than the operator

Manaras Double Limit Switches Mod. (Per Side)

• An extra SPDT pole is available to control auxiliary features such as lights fans etc..
• The additional pole must be specified on either the normally open and/or normally close contact as well as on the opening and/or closing sides
• Modification upcharge is charged per side

Manaras Non-Resettable Counter Modification Inside Control Box

• An electromechanical counter is activated to count each complete door cycle.

Manaras Safepack 24V Control Circuit

• A safepack module is used as an "Intrinsically Safe Barrier Relay" and in hazardous locations with non-voltage producing sensors allowing the user to use a N.O. non-monitored sensing edge.

Manaras Auxiliary Output Module Modification

Manaras Motor 208V/1Ph 60 Hz Modification No extra charge

• The standard 240V/1Ph op. is coverted to 208V/1Ph incoming power supply

Manaras Synthetic Oil Upgrade Only

• This Upgrade Mod. is only available when purchaed with a compatible operator
• Synthetic oil is placed in the operator's reducer for improved performance stability and decreased sensitivity to temperature variances

Manaras Synthetic Oil Upgrade for MGH up to 1.5HP

• This Upgrade Mod. is only available when purchaed with a compatible operator
• Synthetic oil is placed in the operator's reducer for improved performance stability and decreased sensitivity to temperature variances

Micanan Timer to Close 24V Modification

• 3-button o/c/s function timer will start counting from fully open reverse and reset from any device
• 24V modifictation available on control circuit ( R) and ( M) and is included with the new full function smart board (E)

Micanan Apartment Feature: Timer-to-Close Function and Light Control Modification only

• Controlling action of two lights- sockets supplied on cover

Micanan Apartment Feature: Timer-to-Close Function and Light Control Modification only

• Controlling action of two lights- sockets supplied on cover

Micanan Apartment Feature: Timer-to-Close Function and Light Control Modification only

• Controlling action of two lights- sockets supplied on cover

Micanan Apartment Feature: Timer-to-Close Function and Light Control Modification only

• Controlling action of two lights- sockets supplied on cover

Micanan Auxiliary Limit Switch for Monitored ECB

• Installed to control auxiliary device

Micanan Reverse Limit Switches Mod.

• For relay logic models
